Uploading Trashify Box Detector Demo from the videos!

.gitattributes

@@ -33,3 +33,5 @@ saved_model/**/* filter=lfs diff=lfs merge=lfs -text
 *.zip filter=lfs diff=lfs merge=lfs -text
 *.zst filter=lfs diff=lfs merge=lfs -text
 *tfevents* filter=lfs diff=lfs merge=lfs -text
+trashify_examples/trashify_example_2.jpeg filter=lfs diff=lfs merge=lfs -text
+trashify_examples/trashify_example_3.jpeg filter=lfs diff=lfs merge=lfs -text

README.md

@@ -1,12 +1,36 @@
 ---
-title: Trashify Demo V4-video
-emoji: 📊
-colorFrom: red
-colorTo: yellow
+title: Trashify Demo V4 🚮
+emoji: 🗑️
+colorFrom: purple
+colorTo: blue
 sdk: gradio
-sdk_version: 5.38.0
+sdk_version: 5.37.0
 app_file: app.py
 pinned: false
+license: apache-2.0
 ---

-Check out the configuration reference at https://huggingface.co/docs/hub/spaces-config-reference
+# 🚮 Trashify Object Detector V4
+
+Object detection demo to detect `trash`, `bin`, `hand`, `trash_arm`, `not_trash`, `not_bin`, `not_hand`.
+
+Used as example for encouraging people to cleanup their local area.
+
+If `trash`, `hand`, `bin` all detected = +1 point.
+
+## Dataset
+
+All Trashify models are trained on a custom hand-labelled dataset of people picking up trash and placing it in a bin.
+
+The dataset can be found on Hugging Face as [`mrdbourke/trashify_manual_labelled_images`](https://huggingface.co/datasets/mrdbourke/trashify_manual_labelled_images).
+
+## Demos
+
+* [V1](https://huggingface.co/spaces/mrdbourke/trashify_demo_v1) = Fine-tuned [Conditional DETR](https://huggingface.co/docs/transformers/en/model_doc/conditional_detr) model trained *without* data augmentation.
+* [V2](https://huggingface.co/spaces/mrdbourke/trashify_demo_v2) = Fine-tuned Conditional DETR model trained *with* data augmentation.
+* [V3](https://huggingface.co/spaces/mrdbourke/trashify_demo_v3) = Fine-tuned Conditional DETR model trained *with* data augmentation (same as V2) with an NMS (Non Maximum Suppression) post-processing step.
+* [V4](https://huggingface.co/spaces/mrdbourke/trashify_demo_v4) = Fine-tuned [RT-DETRv2](https://huggingface.co/docs/transformers/main/en/model_doc/rt_detr_v2) model trained *without* data augmentation or NMS post-processing (current best mAP).
+
+## Learn more
+
+See the full end-to-end code of how this demo was built at [learnhuggingface.com](https://www.learnhuggingface.com/notebooks/hugging_face_object_detection_tutorial).

app.py

@@ -0,0 +1,178 @@
+
+# 1. Import the required dependencies
+import gradio as gr
+import torch
+# import spaces # for GPU usage
+
+from PIL import Image, ImageDraw, ImageFont
+
+from transformers import AutoImageProcessor, AutoModelForObjectDetection
+
+# Model path = mrdbourke/rt_detrv2_finetuned_trashify_box_detector_v1
+
+# 2. Setup preprocessing and model functions - mrdbourke/rt_detrv2_finetuned_trashify_box_detector_v1
+model_save_path = "mrdbourke/rt_detrv2_finetuned_trashify_box_detector_v1"
+
+# Load image processor
+image_processor = AutoImageProcessor.from_pretrained(model_save_path)
+
+# Default size to 640x640 for simplicity, also handles strange shaped images
+image_processor.size = {"height": 640,
+                        "width": 640}
+
+# Load the model
+model = AutoModelForObjectDetection.from_pretrained(model_save_path)
+
+# Setup the target device (use GPU if it's accessible)
+# Note: if you want to use a GPU in your Space, you can use ZeroGPU: https://huggingface.co/docs/hub/en/spaces-zerogpu
+device = "cuda" if torch.cuda.is_available() else "cpu"
+model = model.to(device)
+
+# Get the id2label dictionary from the model
+id2label = model.config.id2label
+
+# Setup a color dictionary for pretty drawings
+color_dict = {
+    "bin": "green",
+    "trash": "blue",
+    "hand": "purple",
+    "trash_arm": "yellow",
+    "not_trash": "red",
+    "not_bin": "red",
+    "not_hand": "red"
+}
+
+# 3. Create a function predict_on_image
+# Use a GPU on a target function
+# @spaces.GPU
+def predict_on_image(image, conf_threshold):
+  model.eval()
+
+  # Make a prediction on target image
+  with torch.no_grad():
+    inputs = image_processor(images=[image],
+                             return_tensors="pt")
+    model_outputs = model(**inputs.to(device))
+
+    # Get original size of image
+    # PIL.Image.size = width, height
+    # But post_process_object_detection requires height, width
+    target_sizes = torch.tensor([[image.size[1], image.size[0]]]) # -> [batch_size, height, width]
+
+    print(target_sizes)
+
+    # Post process the raw outputs from the model
+    results = image_processor.post_process_object_detection(model_outputs,
+                                                            threshold=conf_threshold,
+                                                            target_sizes=target_sizes)[0]
+
+  # Return all data items/objects to the CPU if they aren't already there
+  for key, value in results.items():
+    try:
+      results[key] = value.item().cpu() # can't get scalars as .item() so add try/except block
+    except:
+      results[key] = value.cpu()
+
+  ### 4. Draw the predictions on the target image ###
+  draw = ImageDraw.Draw(image)
+
+  # Get a font to write on our image
+  font = ImageFont.load_default(size=20)
+
+  # Get a list of the detect class names
+  detected_class_names_text_labels = []
+
+  # Iterate through the predictions of the model and draw them on the target image
+  for box, score, label in zip(results["boxes"], results["scores"], results["labels"]):
+    # Create the coordinates
+    x, y, x2, y2 = tuple(box.tolist()) # XYXY
+
+    # Get the text-based label
+    label_name = id2label[label.item()]
+    targ_color = color_dict[label_name]
+    detected_class_names_text_labels.append(label_name)
+
+    # Draw the rectangle
+    draw.rectangle(xy=(x, y, x2, y2),
+                   outline=targ_color,
+                   width=3)
+
+    # Create the text to display on the box
+    text_string_to_show = f"{label_name} ({round(score.item(), 4)})"
+
+    # Draw the text on the image
+    draw.text(xy=(x, y),
+              text=text_string_to_show,
+              fill="white",
+              font=font)
+
+  # Remove the draw each time to make sure it doesn't get caught in memory
+  del draw
+
+  ### 5. Create logic for outputting information message
+
+  # Setup set of target items to discover
+  target_items = {"trash", "bin", "hand"}
+  detected_items = set(detected_class_names_text_labels)
+
+  # If no items detected or bin, trash, hand not in detected items, return notification
+  if not detected_items & target_items:
+    return_string = (
+        f"No trash, bin or hand detected at confidence threshold {conf_threshold}. "
+        "Try another image or lowering the confidence threshold."
+    )
+    print(return_string)
+    return image, return_string
+
+  # If there are items missing, output what's missing for +1 point
+  missing_items = target_items - detected_items
+  if missing_items:
+    return_string =  (
+        f"Detected the following items: {sorted(detected_items & target_items)}. "
+        f"Missing the following: {missing_items}. "
+        "In order to get +1 point, all target items must be detected."
+    )
+    print(return_string)
+    return image, return_string
+
+  # Final case, all items are detected
+  return_string = f"+1! Found the following items: {sorted(detected_items)}, thank you for cleaning up your local area!"
+  print(return_string)
+  return image, return_string
+
+### 6. Setup the demo application to take in image/conf threshold, pass it through our function, show the output image/text
+
+description = """
+Help clean up your local area! Upload an image and get +1 if there is all of the following items detected: trash, bin, hand.
+
+Model is a fine-tuned version of [RT-DETRv2](https://huggingface.co/docs/transformers/main/en/model_doc/rt_detr_v2#transformers.RTDetrV2Config) on the [Trashify dataset](https://huggingface.co/datasets/mrdbourke/trashify_manual_labelled_images).
+
+See the full data loading and training code on [learnhuggingface.com](https://www.learnhuggingface.com/notebooks/hugging_face_object_detection_tutorial).
+
+This version is v4 because the first three versions were using a different model and did not perform as well, see the [README](https://huggingface.co/spaces/mrdbourke/trashify_demo_v4/blob/main/README.md) for more.
+"""
+
+# Create the Gradio interface
+demo = gr.Interface(
+    fn=predict_on_image,
+    inputs=[
+        gr.Image(type="pil", label="Target Input Image"),
+        gr.Slider(minimum=0, maximum=1, value=0.3, label="Confidence Threshold (set higher for more confident boxes)")
+    ],
+    outputs=[
+        gr.Image(type="pil", label="Target Image Output"),
+        gr.Text(label="Text Output")
+    ],
+    description=description,
+    title="🚮 Trashify Object Detection Demo V4 - Video",
+    examples=[
+        ["trashify_examples/trashify_example_1.jpeg", 0.3],
+        ["trashify_examples/trashify_example_2.jpeg", 0.3],
+        ["trashify_examples/trashify_example_3.jpeg", 0.3],
+    ],
+    cache_examples=True
+)
+
+# Launch demo
+# demo.launch(debug=True) # run with debug=True to see errors in Google Colab
+demo.launch()

requirements.txt

@@ -0,0 +1,4 @@
+timm
+gradio
+torch
+transformers
